GPON SOLUTION Support Price List:

GPON SOLUTION is not a Company, It is a personal website. It is my Freelancing Job. I provide par-time logical support about GPON Technology like OLT/ONT Configure support by CLI & U2000 NMS.

Below are the GPON SOLUTION Support Price List:



For Command line Configuration Support

  1. For Website protected post view password: $25 USD
  2. Huawei OLT Basic Management configure: $50 USD
  3. Huawei ONT Internet Service configure training by CLI: $50 USD
  4. Huawei OLT/ONT VoIP Service configure training by CLI: $100 USD
  5. Huawei OLT/ONT IPTV Service configure training by CLI: $100 USD
  6. Huawei ONT ETH port Trunk / Multiple Tag VLAN configure by CLI: $30 USD
  7. Huawei ONT ETH port QinQ VLAN configure by CLI: $30 USD
  8. ONT to ONT Layer2 Bridge configure within same PON port or same OLT: $30 USD


Third-party ONT add with Huawei OLT

  1. Each Huawei OLT Third-party ONT add feature Unlock Charge: $150USD  to  $300USD
  2. For Huawei MA5600 series OLT Like: MA5608T, MA5603, MA5683, MA5680, MA5600 Model OLT (Control Board MCUD & SCUN with Firmware Version R011 or R015 [ If other version then need to Upgrade/Downgrade to R011 or R015 ] ).
  3. For Huawei MA5800 series OLT Like: MA5800-X7, X15, X17 (Control Board MPLA.

After unlock OLT You can use ZTE, Alcatel/NOKIA, EDGE-CORE, ASKY, Fiberhome, C-DATA, Park, UFiber Nano G, GL-COM, PHY-HOME, Dasan Zhone, V-SOL, VNPT, Huahuan, Blu-Castle, Mikrotik: SFP ONU module and more unspecified Vendor GPON ONT with Huawei OLT.



Huawei GPON NMS Support

Huawei iManager U2000 NMS for MA5600, 5680, 5603, 5683, 5608T & MA5800 X series OLT

  1. U2000 R009 Version without ESN License NMS Price: $100 USD (With Installation)
  2.  Only NMS Install / Re- install Charge: $50 USD
  3. U2000 R014 Version without ESN License NMS Price: $250 USD (With Installation)
  4. U2000 R015 Version without ESN License NMS Price: $300 USD (With Installation)
  5. U2000 R017 Version without ESN License NMS Price: $550 USD (With Installation)
  6. U2000 R015 Version with 1000 ONT License, (With ESN license) NMS Price: $500 USD (With Installation)
  7. Huawei ONT Internet Service configure training by NMS: $50 USD
  8. Huawei OLT/ONT VoIP Service configure training by NMS: $100 USD
  9. Huawei OLT/ONT IPTV Service configure training by NMS: $100 USD
  10. Huawei ONT ETH port Trunk / Multiple Tag VLAN configure by NMS: $30 USD
  11. Huawei ONT ETH port QinQ VLAN configure by NMS: $30 USD
  12. Huawei ONT Remote WAN & WiFi Configure By U2000 NMS: $30 USD (For Internet service like PPPoE, DHCP, Static IP etc by HG8245H gateway ONT.)
  13. Huawei OLT Root  Password Recovery: $100 USD
  14. *Others are depends on service & time.

Note: Difference Between R009 & R015 & R017 Version U2000 NMS is, you can configure ONT WiFi SSID & password by R015/R017 NMS, but not possible by R009 version. Also R009 not support MA5800 x series OLT.

Difference Between Huawei U2000 R009 R014 R015 R017 Version NMS (PDF) Click Here.



Huawei OLT SNMP MIB file price: $30 USD

MA5600TV800R013C00SPC105_MIB



Huawei OLT Firmware Upgrade

Huawei OLT Firmware Upgrade price: $50~$100 USD per OLT.

I have below listed Firmware MA5600 & MA5800 Series Model OLT)

V800R008C02SPH321(C02SPC300)_for_SCUN
V800R010C00SPH107_for_SCUN
V800R011C00SPC102_for_SCUN
V800R013C00SPH207_SCUN
V800R013C10SPH210_SCUN
V800R015C00SPC100_SCUN
V800R015C00SPC101_SCUN

V800R012C00HP1115_MCUD
V800R013C00SPH207_MCUD
V800R013C10SPH210_MCUD
V800R015C00SPC100_MCUD
V800R015C00SPC101_MCUD

Note: R017 & R018 Version Firmware upgrade price: $100 USD

V800R017C10SPH202_SCUN
V800R018C00SPH102_SCUN

V800R017C10SPH202_MCUD
V800R018C00SPH102_MCUD

V800R018C00SPH102_SCUH
V800R018C00SPH102_SCUB
V800R018C00SPH102_SCUK
V800R018C00SPH102_SCUL

V100R017C10SPH215_MPLA



ZTE GPON NMS

  1. ZTE NMS NetNumenU31R20V12.13.20T50 price: $50 USD
  2. ZTE NMS Installation price: $50 USD
  3. ZTE OLT Configuration Guide PDF Price: $50 USD


GPON OLT/ONT Configuration Guide PDF & Hedex Library File Price: $100 USD



If you interested to Buy Service, knock me below E-mail & Skype:

E-mail: shahed.cse06@gmail.com

Skype: shahed.israr


Payment Methods:

1st option: International Master/VISA Credit Card.

2nd option: Payoneer / PayPal / Skrill / Payza or Western Union.



U2000 Huawei iManager U2000 NMS BUY for GPON

U2000 Huawei iManager U2000 NMS BUY for GPON OLT/ONT Monitoring & Management.

If anybody want to Buy Huawei iManager U2000 NMS for GPON OLT/ONT Monitoring & Management, you can contact with me. Below are the details:

I have U2000 R009, R014, R015 & R017 Version NMS.

R017 is latest & support all feature. I have two type license (ESN & Without ESN version). For ESN version you did not get any ESN License error massage.

My Without ESN license not Official that causes it’s have some limitation, such as NMS login time it sometime give you popup massage look like “Failed to match the license file” “ESN license not match with system” & you can not upgrade/update NMS to new/latest version.

But it will not effect your normal working. you can work everything by it look like original. many people are using this non-official version NMS without having major problem.

[If you need logical support to install or learning about U2000 service, like ONT Internet configure, VoIP, IPTV, Remote ONT WAN configure from U2000 etc, need extra charge depends on service]

You can install this NMS any Pc/Server, but for best performance you need good hardware, look like below.

Server Hardware: Intel® Xeon® Processor E5-2670 (2.60GHz).
{For Virtual PC need 4 Logical core & 2 socket per core.}
RAM 8/16GB, HDD 300 GB or SSD 256GB.
C: Drive need 100GB free space.
D: Drive need 150GB free space.
Keep NMS software file/folder in D drive.

Operating System: Windows server 2008 R2 standard version with English Language.

Huawei GPON U2000 NMS Setup Preparation

Its Validity is: unlimited

U2000 Validity

Its license not original that causes it sometime/login time give you a popup massage look like above image”Failed to match the license file” otherwise everything ok.


If you interested to buy this NMS, knock me below E-mail & Skype:

E-mail: shahed.cse06@gmail.com

Skype: shahed.israr

For GPON SOLUTION Support Price List Click Here


For Website protected post view password: $25 USD
U2000R009 NMS + Installation & Basic Setup: $100 USD
U2000R009 + Setup + Support to ONT Internet Configure Training: $150 USD
U2000R015 Without ESN Version NMS Installation Charge: $300 USD
U2000R017 Without ESN Version NMS Installation Charge: $550 USD
VoIP: $100 USD
IPTV: $100 USD
*Others are depends on service & time.


Payment Methods:

1st option: International Master/VISA Credit Card.

2nd option: Payoneer / PayPal / Skrill / Payza or Western Union.


Huawei GPON OLT Configuration

Huawei GPON OLT Configuration:

Here is the some steps for Huawei GPON OLT Configuration. May be it will help you how to configure ONT in OLT & some basic troubleshooting.

GPON Technology Diagram Overview

Huawei OLT Basic Configuration

Create DBA profile in Huawei OLT

Create Traffic Table in Huawei OLT

Register Huawei ONT in Huawei OLT by CLI

GPON FTTH ONT Configure by U2000 NMS

How to configure Huawei ONT in Huawei OLT(Video)

GPON Triple Play Service Configuration (Internet,WiFi, VoIP, IPTV & CATV)

Configure Trunk port in Huawei ONT

Configure QinQ VLAN in Huawei OLT

Huawei ONT Bandwidth Configure

Troubleshoot commands of Huawei ONT

Troubleshooting Command Huawei OLT Part-1

Firmware/Patch Upgrade Huawei OLT

Delete Huawei ONT from OLT

Huawei OLT all Configuration backup procedure

Huawei OLT Factory Default/Erased All config

All Configuration Restore Huawei OLT

Huawei OLT Board List details

User Create Huawei OLT

Control Board Load-sharing Configure

Huawei OLT some configure

Huawei OLT Command list.

GPON, XG-PON, XGS-PON What is the difference?

GPON, XG-PON, XGS-PON, What is the difference?

  • XG-PON, 10-Gigabit-capable passive optical network, provides asymmetric 10G GPON transmission (Maximum downstream line rate: 9.953 Gbit/s, Maximum upstream line rate: 2.488 Gbit/s ).
  • XGS-PON, 10-Gigabit-capable symmetric passive optical network, provides symmetric 10G GPON transmission (Maximum downstream line rate: 9.953 Gbit/s, Maximum upstream line rate: 9.953 Gbit/s ).

Specification Differences Between 10G GPON and GPON

The following table lists specification differences between the two technologies.
Specifications GPON 10G GPON
XG-PON XGS-PON
Wavelength
  • Downstream: 1480-1500 nm
  • Upstream: 1290-1330 nm
  • Downstream: 1575-1580 nm
  • Upstream: 1260-1280 nm
  • Downstream: 1575-1580 nm
  • Upstream: 1260-1280 nm
Center wavelength
  • Downstream: 1490 nm
  • Upstream: 1310 nm
  • Downstream: 1577 nm
  • Upstream: 1270 nm
  • Downstream: 1577 nm
  • Upstream: 1270 nm
Maximum Line Rate
  • Downstream: 2.488 Gbit/s
  • Upstream: 1.244 Gbit/s
  • Downstream: 9.953 Gbit/s
  • Upstream: 2.488 Gbit/s
  • Downstream: 9.953 Gbit/s
  • Upstream: 9.953 Gbit/s
Maximum Physical Transmission Distance

60 km

NOTE:

The physical reach is defined by split ratio, optical module size, and fiber quality.

100 km

NOTE:

The physical reach is defined by split ratio, optical module size, and fiber quality.

100 km

NOTE:

The physical reach is defined by split ratio, optical module size, and fiber quality.

Maximum Split Ratio

1:128

NOTE:

The actual split ratio depends on the optical module model and fiber distance.

1:256

NOTE:

The actual split ratio depends on the optical module model and fiber distance.

1:256

NOTE:

The actual split ratio depends on the optical module model and fiber distance.

No Wavelength Overlap Between GPON and 10G GPON

Figure 1 shows the wavelength distribution of GPON and 10G GPON.
imgDownload?uuid=78baba52e4c74fac81cb950

10G GPON Can Co-exists with GPON in the Same ODN

Figure 2 shows the GPON and 10G GPON can coexist in the same ODN with wavelength division multiplexing (WDM) mode.

imgDownload?uuid=1f15536979c441a59ede0fe





Huawei ONT Naming Rules

Huawei ONT Naming Rule:

This post describe how Huawei ONT each model name provide with its specification.

Product examples:

  • HG8247H: The upstream transmission mode of this ONT is GPON or EPON. It has 2 voice ports and 4 LAN ports (GE ports). It supports USB, CATV, and Wi-Fi.

Overall naming rule: 2 letters+4 digits+(optional) 2 suffixes

Format: A+B+C1+C2+C3+C4+[D]+[E]

Huawei ONT Naming Rules

Field Description

Field Indication
A Upstream transmission mode of an ONT:
– H: PON-based upstream transmission
– L: LAN-based upstream transmission
B Upstream transmission technology of an ONT:
– G: current mainstream technology (EPON/GPON ONT)
– N: next-generation technology (10G PON ONT)
– S: smart ONT
C1 UNI-side port and IoT protocol compliance status:
– 8: mainstream ONT with PON upstream transmission
– 2: ZigBee-compliant ONT
C2 Number of voice ports. For example, 0 indicates no POTS ports, and 2 indicates 2 POTS ports.
C3 Number of LAN ports. For example, 0 indicates no LAN ports, and 4 indicates 4 LAN ports.
C4 Function support, indicated by a decimal value converted from a 3-bit binary number. 0 in binary indicates that a function is not supported, while 1 in binary indicates that a function is supported. USB, CATV, and Wi-Fi refer to the USB, CATV, and Wi-Fi functions of an ONT.
For example, if all these 3 functions are supported, the binary number is 111 and the corresponding decimal value is 7.
D Highlighted feature or customization. For example:
– C: customized for China Telecom
– M: customized for China Mobile
– H: GE LAN port
– S: outdoor
– V: dual-band Wi-Fi, for example, HG8145V5 supports 11n 2×2 MIMO(2.4G) and 11ac 2×2 MIMO(5G)
– Q: dual-band Wi-Fifor example, HN8055Q supports 11n 3×3 MIMO(2.4G) and 11ac 3×3 MIMO(5G)
– W: dual-band Wi-Fi for example, HG8245W supports 11n 2×2 MIMO(2.4G) and 11ac 4×4 MIMO(5G)
E Extra information. For example:5 indicates a V5 platform product, and s indicates an XGS-PON product.

Note: For a version customized for China Unicom, the ONT name starts with 83, and the subsequent digits indicate the number of Ethernet ports and number of POTS ports. The name of a gateway ONT ends with R.

Product examples:

  • HG8247H: The upstream transmission mode of this ONT is GPON or EPON. It has 2 voice ports and 4 LAN ports (GE ports). It supports USB, CATV, and Wi-Fi.
  • HN8255Ws: The upstream transmission mode of this ONT is XGS-PON. It has 2 voice ports and 5 LAN ports. It supports USB and dual-band Wi-Fi (11ac 4×4 MIMO).



Alcatel OLT/ONT Troubleshooting Command details

Alcatel OLT/ONT Troubleshooting Command details:

Below are the details Alcatel OLT/ONT Troubleshooting Command.

typ:isadmin># show equipment slot

typ:isadmin># show equipment ont interface
typ:isadmin># show equipment ont slot
typ:isadmin># show equipment ont optics

typ:isadmin># show pon optics

typ:isadmin># show equipment ont sw-download

typ:isadmin># show equipment ont interface
typ:isadmin># show equipment ont interface 1/1/3/10/1 detail

typ:isadmin># show vlan fdb-board
typ:isadmin># show service fdb-mac

typ:isadmin># show interface port uni:1/1/3/10/1/1/1
typ:isadmin># show interface port uni:1/1/3/10/1/1/1 detail

typ:isadmin># show ethernet ont operational-data
typ:isadmin># show ethernet ont operational-data detail

typ:isadmin># show port

typ:isadmin># show equipment transceiver-inventory nt-a:xfp:1
typ:isadmin># show equipment transceiver-inventory nt-a:xfp:1 detail

typ:isadmin># show equipment diagnostics sfp nt-a:xfp:1 detail

typ:isadmin># show software-mngt version etsi
typ:isadmin># show equipment ont sw-version

typ:isadmin># info configure service

typ:isadmin># info configure bridge port flat

typ:isadmin># info configure vlan id flat

typ:isadmin># info configure qos profiles bandwidth configure qos profiles

typ:isadmin># show equipment ont interface
===========================================================================================================
interface table
===========================================================================================================
| | |actual | | | |cfgfile1|cfgfile2
ont-idx |eqpt-ver-num|sw-ver-act|num-slots|version-number|sernum |yp-serial-no|ver-act |ver-act
-------------+------------+----------+---------+--------------+-------------+------------+--------+--------
1/1/3/10/1 3FE56389ABA* 3FE56065A* 1 3FE56389ABAB01 ALCL:FAE3D60E FAE3D60E
1/1/3/10/2 3FE56389ABA* 3FE56065A* 1 3FE56389ABAB01 ALCL:FAE3BBB9 FAE3BBB9
-----------------------------------------------------------------------------------------------------------
interface count : 2
===========================================================================================================

typ:isadmin># show equipment ont slot
================================================================================
slot table
================================================================================
| act-num | actual |
ont-slot-idx |data-ports voice-ports|card-type serial-num|state
—————-+———-+———–+———–+———-+—————–
1/1/3/10/1/1 1 0 ethernet FAE3D60E disabled
1/1/3/10/2/1 1 0 ethernet FAE3BBB9 disabled
——————————————————————————–
slot count : 2
================================================================================

typ:isadmin># show equipment ont optics
=======================================================================================
optics table
=======================================================================================
|rx-signal |tx-signal |ont | |laser |olt-rx
ont-idx |level |level |temperature|ont-voltage|bias-curr |sig-level
————-+———–+———–+———–+———–+————-+———–
1/1/3/10/1 -16.180 2.316 37.898 3.30 13900.0 -17.3
1/1/3/10/2 -16.990 2.904 31.301 3.28 12800.0 -18.2
—————————————————————————————
optics count : 2
=======================================================================================

typ:isadmin># show pon optics
================================================================================
optics table
================================================================================
pon-idx |olt-tx-signal-lvl|olt-temperature|olt-voltage |olt-laser-curr
———+—————–+—————+————-+———————-
1/1/3/1 3.600000 62.029999 3.310000 18
1/1/3/2 not-supported not-supported not-supported not-supported
1/1/3/16 not-supported not-supported not-supported not-supported
1/1/4/1 3.500000 55.540001 3.280000 17
1/1/4/2 not-supported not-supported not-supported not-supported
1/1/4/16 not-supported not-supported not-supported not-supported
1/1/5/1 invalid invalid invalid invalid
1/1/5/2 invalid invalid invalid invalid
1/1/5/3 invalid invalid invalid invalid

——————————————————————————–
optics count : xx
================================================================================

typ:isadmin># show equipment ont sw-download
======================================================================================================
sw-download table
======================================================================================================
| |download |ntlt |omci |ontswact |download |sw-version|sw-download
ont-idx |planned|inprogress|inprogress|inprogress|inprogress|file-notfound|mismatch |failure
————-+——-+———-+———-+———-+———-+————-+———-+———–
1/1/3/1/1 yes no no no no no no no
1/1/4/1/1 yes no no no no no no no
——————————————————————————————————
sw-download count : 2
======================================================================================================

ONT delete:
===============
typ:isadmin># configure equipment ont interface 1/1/3/10/1 admin-state down
typ:isadmin>configure>equipment>ont>interface>1/1/3/10/1# configure equipment ont no interface 1/1/3/10/1

70/01/06 04:07:47 minor alarm occurred for pon 1/1/3/10 : SERNUM =ALCLFAE3D60E, SLID =DEFAULT , LOID =

typ:isadmin># show equipment ont interface
===========================================================================================================
interface table
===========================================================================================================
| | |actual | | | |cfgfile1|cfgfile2
ont-idx |eqpt-ver-num|sw-ver-act|num-slots|version-number|sernum |yp-serial-no|ver-act |ver-act
————-+————+———-+———+————–+————-+————+——–+——–
1/1/3/10/2 3FE56389ABA* 3FE56065A* 1 3FE56389ABAB01 ALCL:FAE3BBB9 FAE3BBB9
———————————————————————————————————–
interface count : 1
===========================================================================================================

typ:isadmin>configure>equipment>ont>interface>1/1/3/1/1$ show equipment ont interface detail
================================================================================
interface table (detailed)
================================================================================

——————————————————————————–
interface
——————————————————————————–
ont-idx : 1/1/3/1/1 eqpt-ver-num :
sw-ver-act : sw-ver-psv :
vendor-id :
equip-id :
actual-num-slots : 0 version-number :
num-tconts : 0 num-trf-sched : 0
num-prio-queues : 0 auto-sw-planned-ver :
auto-sw-download-ver : sernum : ALCL:FAE3BBB9
yp-serial-no : unknown
oper-spec-ver : unknown act-ont-type : unknown
act-txpower-ctrl : unknown sn-bundle-status : idle
cfgfile1-ver-act : cfgfile1-ver-psv :
cfgfile2-ver-act : cfgfile2-ver-psv :
================================================================================

================================================================================================================================================
typ:isadmin># show equipment ont interface 1/1/3/10/1 detail
================================================================================================================================================
interface table (detailed)
================================================================================================================================================
————————————————————————————————————————————————
interface
————————————————————————————————————————————————
ont-idx : 1/1/3/10/1 eqpt-ver-num : 3FE56389ABAB01 sw-ver-act : 3FE56065AFDB44 sw-ver-psv : 3FE56065AFAB30
vendor-id : ALCL equip-id : BVMDP00CRAG010GA actual-num-slots : 1 version-number : 3FE56389ABAB01
num-tconts : 32 num-trf-sched : 32 num-prio-queues : 124 auto-sw-planned-ver :
auto-sw-download-ver : sernum : ALCL:FAE3BBB9
yp-serial-no : FAE3BBB9
oper-spec-ver : unknown act-ont-type : sfu act-txpower-ctrl : tx-rx sn-bundle-status : idle
cfgfile1-ver-act : cfgfile1-ver-psv : cfgfile2-ver-act : cfgfile2-ver-psv :
================================================================================================================================================

typ:isadmin># show equipment ont interface 1/1/3/1/1 detail
================================================================================
interface table (detailed)
================================================================================

——————————————————————————–
interface
——————————————————————————–
ont-idx : 1/1/3/1/1 eqpt-ver-num : 3FE54857ABBA__
sw-ver-act : 3FE54754141123 sw-ver-psv : not-supported
vendor-id : ALCL
equip-id : ____I-120E-Q____
actual-num-slots : 2 version-number : 3FE54857ABBA__
num-tconts : 8 num-trf-sched : 8
num-prio-queues : 56 auto-sw-planned-ver :
auto-sw-download-ver : sernum : ALCL:FAAEC355
yp-serial-no : unknown
oper-spec-ver : unknown act-ont-type : unknown
act-txpower-ctrl : unknown sn-bundle-status : idle
================================================================================

typ:isadmin># info configure service
———————————————-
customer 1 create
description “Default customer”
exit
ies 2 customer 1 create
interface “OAM” create
address 10.200.200.2/24
sap nt:vp:1:3 create
exit
exit
interface “TEST” create
address 192.168.10.2/24
sap nt:vp:1:2001 create
exit
exit
no shutdown
exit
vpls 3 customer 1 v-vpls vlan 3 create
stp
shutdown
exit
sap nt-a:eth:1:0 create
exit
sap nt-a:xfp:1:3 create
exit
no shutdown
exit
vpls 1721 customer 1 v-vpls vlan 1721 create
stp
shutdown
exit
sap nt-a:xfp:3:1721 create
exit
sap lt:1/1/3:1721 create
exit
no shutdown
exit

———————————————-
typ:isadmin># info configure bridge port flat
configure bridge port 1/1/3/10/1/1/1 max-unicast-mac 100
configure bridge port 1/1/3/10/1/1/1 vlan-id 2000 tag single-tagged
configure bridge port 1/1/3/10/1/1/1 vlan-id 2001 tag single-tagged
configure bridge port 1/1/3/10/2/1/1 max-unicast-mac 100
configure bridge port 1/1/3/10/2/1/1 vlan-id stacked:1721:0 tag single-tagged
configure bridge port 1/1/3/10/2/1/1 pvid stacked:1721:0
#——————————————————————————-

typ:isadmin># info configure vlan id flat
configure vlan id 3 mode residential-bridge in-qos-prof-name name:GULSHAN
configure vlan id 2000 mode residential-bridge in-qos-prof-name name:GULSHAN
configure vlan id 2001 mode residential-bridge in-qos-prof-name name:GULSHAN
configure vlan id stacked:1721:0 mode residential-bridge in-qos-prof-name name:GULSHAN
#——————————————————————————-

typ:isadmin># show vlan fdb-board
================================================================================
fdb-board table
================================================================================
slot |fdb-id |mac |status |sub-mac
———+—————–+—————–+——-+————————–
lt:1/1/3 2000 04:c5:a4:b6:6f:18 learned 04:c5:a4:b6:6f:18
lt:1/1/3 2001 60:e3:27:03:95:00 learned 60:e3:27:03:95:00
——————————————————————————–
fdb-board count : 2
================================================================================

typ:isadmin># show service fdb-mac

===============================================================================
Service Forwarding Database
===============================================================================
ServId MAC Source-Identifier Type Last Change
Age
——————————————————————————-
3 fc:48:ef:c5:11:83 sap:nt-a:xfp:1:3 L/0 01/07/1970 02:42:17
3 fc:48:ef:c5:14:dd sap:nt-a:xfp:1:3 L/0 01/07/1970 02:25:36
1721 24:b6:fd:18:1b:d9 sap:nt-a:xfp:3:1721 L/0 01/07/1970 02:43:13
1721 50:7b:9d:3a:21:c3 sap:lt:1/1/3:1721 L/0 01/07/1970 02:46:39
1721 64:d8:14:ba:78:01 sap:nt-a:xfp:3:1721 L/0 01/07/1970 02:43:14
2000 00:0b:82:23:87:9e sap:nt-a:xfp:1:2000 L/252 01/07/1970 02:43:16
2000 00:0e:30:00:de:12 sap:nt-a:xfp:1:2000 L/245 01/07/1970 02:43:23
2000 f8:bc:12:6e:e2:0d sap:nt-a:xfp:1:2000 L/75 01/07/1970 02:45:17
2001 80:38:bc:1a:c9:77 sap:nt-a:xfp:1:2001 L/187 01/07/1970 02:44:21
——————————————————————————-
No. of Entries: 9
——————————————————————————-
Legend: L=Learned; P=MAC is protected
===============================================================================

typ:isadmin># show interface port uni:1/1/3/10/1/1/1
================================================================================
port table
================================================================================
port |admin-status|opr-status
—————————————————+————+—————
uni:1/1/3/10/1/1/1 up up
——————————————————————————–
port count : 1
================================================================================

typ:isadmin># show ethernet ont operational-data
================================================================================
operational-data table
================================================================================
uni-idx |config-indicator|link-status
——————-+—————-+——————————————-
1/1/3/10/1/1/1 100baset-fd up
1/1/3/10/2/1/1 100baset-fd up
——————————————————————————–
operational-data count : 2
================================================================================

typ:isadmin># show ethernet ont operational-data detail
================================================================================
operational-data table (detailed)
================================================================================

——————————————————————————–
operational-data
——————————————————————————–
uni-idx : 1/1/3/10/1/1/1
config-indicator : 100baset-fd link-status : up
——————————————————————————–
operational-data
——————————————————————————–
uni-idx : 1/1/3/10/2/1/1
config-indicator : 100baset-fd link-status : up
================================================================================

typ:isadmin># show ethernet ont operational-data
================================================================================
operational-data table
================================================================================
uni-idx |config-indicator|link-status
——————-+—————-+——————————————-
1/1/3/10/1/1/1 gige-fd up
1/1/3/10/2/1/1 100baset-fd up
——————————————————————————–
operational-data count : 2
================================================================================

typ:isadmin># show interface port uni:1/1/3/10/1/1/1 detail
================================================================================
port table (detailed)
================================================================================

——————————————————————————–
port
——————————————————————————–
port : uni:1/1/3/10/1/1/1
if-index : 135397440
info : “alcatel FGLT-B PHYSICALUNI”
type : uni
name : ” PHYSICALUNI”
high-speed : 0 connector-present : not-applicable
media : 0.0
largest-pkt-size : 0 current-bandwidth : 0
phy-addr :
admin-status : up opr-status : up
last-chg-opr-stat : 000-06:07:30 pkts-unknown-proto : 0
in-octets : 0 out-octets : 0
in-ucast-pkts : 0 out-ucast-pkts : 0
in-mcast-pkts : 0 out-mcast-pkts : 0
in-broadcast-pkts : 0 out-broadcast-pkts : 0
in-discard-pkts : 0 out-discard-pkts : 0
in-err-pkts : 0 out-err-pkts : 0
in-octets-hc : 0
out-octets-hc : 0
in-ucast-pkts-hc : 0
out-ucast-pkts-hc : 0
in-mcast-pkts-hc : 0
out-mcast-pkts-hc : 0
in-broadcast-pkts-hc : 0
out-broadcast-pkts-hc : 0
================================================================================

typ:isadmin># show port

===============================================================
Ports on NT
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt:vp:1 Up Yes Up 1518 1518 – accs dotq vport
nt:mc:1 Up Yes Up 1518 1518 – accs dotq vport

===============================================================
Ports on NT-A
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-a:ieee1588:1
Down No Down 9212 9212 – accs dotq xcme

===============================================================
Ports on NT-B
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-b:ieee1588:1
Down No Down 9212 9212 – accs dotq xcme

===============================================================
Ports on NT-A
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-a:eth:1 Up No Down 9212 9212 – accs dotq xcme
nt-a:xfp:1 Up Yes Up 9212 9212 – accs dotq gige
nt-a:xfp:2 Down No Down 9212 9212 – accs dotq gige
nt-a:xfp:3 Down No Down 9212 9212 – accs dotq gige
nt-a:xfp:4 Down No Down 9212 9212 – accs dotq gige

===============================================================
Ports on NT-B
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-b:eth:1 Down No Down 9212 9212 – accs dotq xcme
nt-b:xfp:1 Down No Down 9212 9212 – accs dotq gige
nt-b:xfp:2 Down No Down 9212 9212 – accs dotq gige
nt-b:xfp:3 Down No Down 9212 9212 – accs dotq gige
nt-b:xfp:4 Down No Down 9212 9212 – accs dotq gige

===============================================================
Ports on LT
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
lt:1/1/1 Up No Down 9212 9212 – accs dotq lt
lt:1/1/2 Up No Down 9212 9212 – accs dotq lt
lt:1/1/3 Up Yes Up 9212 9212 – accs dotq lt
lt:1/1/4 Up No Down 9212 9212 – accs dotq lt
lt:1/1/5 Up No Down 9212 9212 – accs dotq lt
lt:1/1/6 Up No Down 9212 9212 – accs dotq lt
lt:1/1/7 Up No Down 9212 9212 – accs dotq lt
lt:1/1/8 Up No Down 9212 9212 – accs dotq lt

===============================================================
Ports on NT-A
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-a:AI:1 Down No Down 9212 9212 – accs dotq gige

===============================================================
Ports on NT-B
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-b:AI:1 Down No Down 9212 9212 – accs dotq gige
===============================================================

Interface UP”
================

typ:isadmin># configure port nt-a:xfp:3 ethernet no autonegotiate
typ:isadmin># configure port nt-a:xfp:3 ethernet speed 1000
typ:isadmin># configure port nt-a:xfp:3 no shutdown

70/01/02 20:06:11 critical alarm occurred for nt-a:xfp:3 (service affecting) : Ethernet Link Down alarm

typ:isadmin># show port

===============================================================
Ports on NT
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt:vp:1 Up Yes Up 1518 1518 – accs dotq vport
nt:mc:1 Up Yes Up 1518 1518 – accs dotq vport

===============================================================
Ports on NT-A
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-a:ieee1588:1
Down No Down 9212 9212 – accs dotq xcme

===============================================================
Ports on NT-B
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-b:ieee1588:1
Down No Down 9212 9212 – accs dotq xcme

===============================================================
Ports on NT-A
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-a:eth:1 Up No Down 9212 9212 – accs dotq xcme
nt-a:xfp:1 Up Yes Up 9212 9212 – accs dotq gige
nt-a:xfp:2 Down No Down 9212 9212 – accs dotq gige
nt-a:xfp:3 Up No Down 9212 9212 – accs dotq gige
nt-a:xfp:4 Down No Down 9212 9212 – accs dotq gige

===============================================================
Ports on NT-B
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-b:eth:1 Down No Down 9212 9212 – accs dotq xcme
nt-b:xfp:1 Down No Down 9212 9212 – accs dotq gige
nt-b:xfp:2 Down No Down 9212 9212 – accs dotq gige
nt-b:xfp:3 Down No Down 9212 9212 – accs dotq gige
nt-b:xfp:4 Down No Down 9212 9212 – accs dotq gige

===============================================================
Ports on LT
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
lt:1/1/1 Up No Down 9212 9212 – accs dotq lt
lt:1/1/2 Up No Down 9212 9212 – accs dotq lt
lt:1/1/3 Up Yes Up 9212 9212 – accs dotq lt
lt:1/1/4 Up No Down 9212 9212 – accs dotq lt
lt:1/1/5 Up No Down 9212 9212 – accs dotq lt
lt:1/1/6 Up No Down 9212 9212 – accs dotq lt
lt:1/1/7 Up No Down 9212 9212 – accs dotq lt
lt:1/1/8 Up No Down 9212 9212 – accs dotq lt

===============================================================
Ports on NT-A
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-a:AI:1 Down No Down 9212 9212 – accs dotq gige

===============================================================
Ports on NT-B
===============================================================
Port Admin Link Port Cfg Oper LAG/ Port Port Port
Id State State MTU MTU Bndl Mode Encp Type
—————————————————————
nt-b:AI:1 Down No Down 9212 9212 – accs dotq gige
===============================================================

typ:isadmin># show equipment transceiver-inventory nt-a:xfp:3
=================================================================================================
transceiver-inventory table
=================================================================================================
index |inventory-status |alu-part-num|tx-wavelength|fiber-type |rssi-sfptype
———————-+——————+————+————-+————-+————–
nt-a:xfp:3 cage-empty not-availab* not-available not-available not-available
————————————————————————————————-
transceiver-inventory count : 1
=================================================================================================

typ:isadmin># show equipment transceiver-inventory nt-a:xfp:1
=================================================================================================
transceiver-inventory table
=================================================================================================
index |inventory-status |alu-part-num|tx-wavelength|fiber-type |rssi-sfptype
———————-+——————+————+————-+————-+————–
nt-a:xfp:1 no-error 3FE62600DA “1310 nm” single-mode 10gbase_lr
————————————————————————————————-
transceiver-inventory count : 1
=================================================================================================

typ:isadmin># show equipment transceiver-inventory nt-a:xfp:1 detail
================================================================================
transceiver-inventory table (detailed)
================================================================================

——————————————————————————–
transceiver-inventory
——————————————————————————–
index : nt-a:xfp:1
inventory-status : no-error
alu-part-num : 3FE62600DA
clei-code : VAI2AE0DAA
tx-wavelength : “1310 nm”
fiber-type : single-mode
mfg-name : WTD
mfg-oui : 001CAD
mfg-date : 14/11/2015
vendor-serial-num : WHTDCN15463683
additional-info : I
rssi-sfptype : 10gbase_lr
================================================================================

70/01/02 20:30:25 critical alarm occurred for nt-a:xfp:1 (service affecting) : Ethernet Link Down alarm

typ:isadmin># show equipment diagnostics sfp nt-a:xfp:1
=======================================================================================
sfp table
=======================================================================================
| | | | rssi
position |diag-avail-status |los |tx-fault |profile-id state
———————-+——————+————-+————–+———-+—–
nt-a:xfp:1 no-error no-los no-tx-fault 65535 no
—————————————————————————————
sfp count : 1
=======================================================================================

typ:isadmin># show equipment diagnostics sfp nt-a:xfp:1 detail
================================================================================
sfp table (detailed)
================================================================================

——————————————————————————–
sfp
——————————————————————————–
position : nt-a:xfp:1
diag-avail-status : no-error
los : no-los tx-fault : no-tx-fault
tx-power : “-3.95 dBm”
rx-power : “-1.93 dBm”
tx-bias-current : “42.17 mA”
supply-voltage : “3.31 VDC”
temperature : “60.16 degrees Celsius”
temperature-tca : normal-value
voltage-tca : normal-value
bias-current-tca : normal-value
tx-power-tca : normal-value
rx-power-tca : normal-value
rssi-profile-id : 65535 rssi-state : disable
================================================================================

typ:isadmin># show equipment diagnostics sfp nt-a:xfp:3 detail
================================================================================
sfp table (detailed)
================================================================================

——————————————————————————–
sfp
——————————————————————————–
position : nt-a:xfp:3
diag-avail-status : cage-empty
los : not-available tx-fault : not-available
tx-power : not-available
rx-power : not-available
tx-bias-current : not-available
supply-voltage : not-available
temperature : not-available
temperature-tca : not-available
voltage-tca : not-available
bias-current-tca : not-available
tx-power-tca : not-available
rx-power-tca : not-available
rssi-profile-id : 65535 rssi-state : disable
================================================================================

typ:isadmin># show software-mngt version etsi
================================================================================
etsi table
================================================================================
isam-release : R5.3.01
================================================================================

typ:isadmin># show equipment ont sw-version
================================================================================
sw-version table
================================================================================
sw-ver-id|sw-ver |sw-ver-size
———+————–+——————————————————-
1 FE56065AFDB44 7483286
——————————————————————————–
sw-version count : 1
================================================================================

typ:isadmin># show equipment slot
================================================================================
slot table
================================================================================
slot |actual-type|enabled|error-status |availability |restrt-cnt
———+———–+——-+———————-+————-+————-
acu:1/1 ngfc-e no no-planned-board available 0
nt-a fant-f yes no-error available 0
nt-b empty no no-error not-installed 0
lt:1/1/1 empty no no-error not-installed 0
lt:1/1/2 empty no no-error not-installed 0
lt:1/1/3 empty no no-error not-installed 0
lt:1/1/4 empty no no-error not-installed 0
lt:1/1/5 empty no no-error not-installed 0
lt:1/1/6 empty no no-error not-installed 0
lt:1/1/7 empty no no-error not-installed 0
lt:1/1/8 empty no no-error not-installed 0
——————————————————————————–
slot count : 11
================================================================================

typ:isadmin># configure pon interface 1/1/3/[1…16] fec-dn disable admin-state up

typ:isadmin># configure pon interface 1/1/3/1 fec-dn disable admin-state up
typ:isadmin># configure pon interface 1/1/3/1 fec-dn disable admin-state up
.
.
.
typ:isadmin># configure pon interface 1/1/3/15 fec-dn disable admin-state up
typ:isadmin># configure pon interface 1/1/3/16 fec-dn disable admin-state up
typ:isadmin>#

typ:isadmin># info configure qos profiles bandwidth configure qos profiles
#——————————————————————————-
echo “qos”
#——————————————————————————-
bandwidth 1MB committed-info-rate 0 assured-info-rate 0 excessive-info-rate 1024
delay-tolerance 32
exit
bandwidth 100MB committed-info-rate 0 assured-info-rate 0 excessive-info-rate 100000
delay-tolerance 32
exit
#——————————————————————————-

bandwidth-profile change/apply:
================================

typ:isadmin># configure qos interface 1/1/3/10/2/1/1 upstream-queue 0 bandwidth-
profile name:?
100MB !
1MB !
typ:isadmin># configure qos interface 1/1/3/10/2/1/1 upstream-queue 0 bandwidth-
profile name:1MB bandwidth-sharing uni-sharing
typ:isadmin>configure>qos>interface>1/1/3/10/2/1/1>upstream-queue>0# info
configure qos interface 1/1/3/10/2/1/1
#——————————————————————————-
echo “qos”
#——————————————————————————-
upstream-queue 0
bandwidth-profile name:1MB
bandwidth-sharing uni-sharing
exit
#——————————————————————————-
typ:isadmin>configure>qos>interface>1/1/3/10/2/1/1>upstream-queue>0# exit all

Bandwidth profile remove/open:
==============================

typ:isadmin># configure qos interface 1/1/3/10/2/1/1 upstream-queue 0 no bandwid
th-profile
typ:isadmin>configure>qos>interface>1/1/3/10/2/1/1>upstream-queue>0# info
configure qos interface 1/1/3/10/2/1/1
#——————————————————————————-
echo “qos”
#——————————————————————————-
upstream-queue 0
bandwidth-sharing uni-sharing
exit
#——————————————————————————-

Static route ADD:
=================

typ:isadmin># configure router static-route 0.0.0.0/0 next-hop 10.200.200.1

typ:isadmin># info configure router
———————————————-
#————————————————–
echo “IP Configuration”
#————————————————–
interface “system”
exit
#————————————————–
echo “Static Route Configuration”
#————————————————–
static-route 0.0.0.0/0 next-hop 10.200.200.1
———————————————-

IP Address put in VLAN interface:
=================================

typ:isadmin># configure service ies 2 customer 1 create
typ:isadmin>configure>service>ies# configure service ies 2 interface “OAM” create
typ:isadmin>configure>service>ies>if# configure service ies 2 interface “OAM” address 10.200.200.2/24
typ:isadmin>configure>service>ies>if# configure service ies 2 interface “OAM” sap nt:vp:1:3 create
typ:isadmin>configure>service>ies>if>sap# configure service ies 2 no shutdown
typ:isadmin>configure>service>ies>if>sap# exit all

typ:isadmin># info configure service
———————————————-
customer 1 create
description “Default customer”
exit
ies 2 customer 1 create
interface “OAM” create
address 10.200.200.2/24
sap nt:vp:1:3 create
exit
exit
no shutdown
exit
———————————————-

typ:isadmin># configure port nt-a:eth:1 ethernet speed 1000
typ:isadmin># configure port nt-a:eth:1 no shutdown

typ:isadmin># configure service vpls 3 sap nt-a:eth:1:0 create
MINOR: SVCMGR #1601 Invalid SAP-id – Already sap is present with non zero encap value
typ:isadmin># configure service vpls 3 s
sap send-flush-on-failure service-mtu
sgt-qos shutdown spoke-sdp
storm-control stp

typ:isadmin># configure service vpls 3 shutdown
typ:isadmin># configure service vpls 3 no sap nt-a:eth:1:3
MINOR: SVCMGR #1613 The SAP can’t be deleted – The SAP must be shutdown first

typ:isadmin># configure service vpls 3 sap nt-a:eth:1:3 shutdown
typ:isadmin># configure service vpls 3 no sap nt-a:eth:1:3

typ:isadmin># info configure service
———————————————-
customer 1 create
description “Default customer”
exit
ies 2 customer 1 create
interface “OAM” create
address 10.200.200.2/24
sap nt:vp:1:3 create
exit
exit
no shutdown
exit
vpls 3 customer 1 v-vpls vlan 3 create
shutdown
stp
shutdown
exit
sap nt-a:xfp:1:3 create
exit
exit
———————————————-
typ:isadmin># configure service vpls 3 sap nt-a:eth:1:0 create
typ:isadmin>configure>service>vpls>sap# configure service vpls 3 no shutdown

typ:isadmin># admin save
Writing configuration to /pub/IPD/dm/config.cfg
Saving configuration … OK
Completed.

Protected: Control Board Load-sharing Configure in Huawei OLT

This content is password protected. To view it please enter your password below:

Huawei OLT Important Configure

Huawei OLT Important Configure:

Today i will share Huawei OLT Important Configure, hope it will help you.

Huawei OLT  Default control Card (MCUD,SCUN) ETH port IP: 10.11.104.2/24
Huawei OLT Standard login: root, password: admin

Connect to the console port (CON) and prescribe IP management in a managed VLAN ID 10:
enable
config
vlan 10 smart
vlan desc 10 description “Management”
port vlan 10 0/8 0
interface vlanif10
ip address 192.168.10.2 255.255.255.0
quit
ip route-static 0.0.0.0 0.0.0.0 192.168.10.1

Alternatively, you can assign an IP meth special port for management instead of default ip 10.11.104.2(then have to be connected to the OLT excess cable):
interface meth 0
ip address 192.168.1.2 24
quit

EXAMPLE setting time:
time 11:24:00
time 11:24:00 2016-11-06
display time
timezone GMT+ 02:00
display timezone
display time dst
display time time-stamp
display time-range
ntp-service Subcommands
display ntp-service

Example configuration export to the tftp server:
Gponsolution-MA5683T(config)#backup configuration tftp 10.11.104.1 old_config.cfg
Gponsolution-MA5683T(config)#backup data tftp 10.11.104.1 old_data.dat
Gponsolution-MA5683T(config)#backup bios tftp 10.11.104.1 old_bios.bin
Gponsolution-MA5683T(config)#backup program tftp 10.11.104.1 old_program.efs

error: Content is protected !!
